Low Voltage Series for Energy Storage System
Residential energy storage system, modular high- voltage battery, suitable for residential energy storage, One set provides electricity for the whole house.
Product Introduction
A low voltage storage system typically consists of batteries, a charge controller, and an inverter. The batteries store the energy generated through solar panels or other sources, while the charge controller manages the charging and discharging of the batteries, ensuring that they are not overcharged or drained beyond a safe level. The inverter converts the stored DC energy into AC energy that can be used to power electrical devices.
Features
LED lights display the parameters of the equipment in real time
Modular structure for easy installation
Intelligent battery management system
Long cycle life
Supports up to 16 clusters in parallel
Can be used with hybrid inverter .
Support a variety of communication protocols, support RS485, RS232, CAN etc
Specification
| Basic Parameters | 1-module | 2-module | 3-module | 4-module | 5-module | 6-module |
| Nominal Capacity(KWh) | 5.12 | 10.24 | 15.36 | 20.48 | 25.6 | 30.72 |
| Nominal voltage (V) | 51.2 | |||||
| Weight (Kg) | 80 | 125 | 170 | 215 | 260 | 305 |
| Dimension(WxDxH)(mm) |
600x400x385 |
600x400x534 |
600x400x683 |
600x400x832 |
600x400x981 |
600x400x1130 |
| Battery Type | LFP(LiFePO4) | |||||
| Discharge Cut-off Voltage(V) | 43.2V(16S) | |||||
| Charge Cut-off Voltage(Vv) | 58.4V(16S) | |||||
| Communication Port | RS485,RS232 CAN | |||||
| Cell series number | 16 | |||||
| Working Temperature("℃) | -10°℃~60℃ | |||||
| Design life | 10+Years(25°℃) | |||||
| Cycle life | >6000(25°℃) | |||||
| Recommended charge current | ≤50A | |||||
| Max. continuous charge current(A) | 100A | |||||
| Max. continuous discharge current(A) | 100A | |||||
| Max, unit in Parallel(pcs) | 16 | |||||
| Warranty | 3 Years | |||||
